The Dino road cars came to be because of Enzo Ferrari's need to homologate a V6 engine for Formula 2 racing cars. In 1965 the Commission Sportive Internationale de la FIA had drawn up new rules, to be enacted for the 1967 season. F2 engines were required to have no more than six cylinders, and to be derived from a production engine, from a road car homologated in the GT class and produced in at least 500 examples within 12 months.[2][3][4] Since a small manufacturer, like Ferrari was in the mid 60s, did not possess the production capacity to reach such quotas, an agreement was signed with Fiat and made public on 1 March 1965: Fiat would produce the 500 engines needed for the homologation, to be installed in a GT car which remained to be specified.[3][4]
Dino was the nickname of Enzo's son Alfredo Ferrari, who had died in 1956 and was credited with the concept for Ferrari's Formula 2 V6 racing engine, believed to be designed by Vittorio Jano with a peculiar 65° angle between the cylinder banks.[2] In his memory, V6-engined Ferrari sports prototype racing cars had been named Dino since the late 1950s. The conversion of this racing engine for road use and series production was entrusted to the engineer Aurelio Lampredi, who had previously designed several 4-cylinder Ferrari engines. Interviewed in the early 1980s, Lampredi noted that "things didn't work out exactly as Ferrari had foreseen": Enzo Ferrari had counted on building the engines at Maranello, but Fiat's management insisted on taking control of production, to avoid any breaks in the engine supply. The resulting Fiat-built V6 ended up being installed in two very different vehicles: the Fiat Dino, a front-engined grand tourer assembled in Turin by Fiat, and in Ferrari's first series-produced mid-engined sports car, built in Maranello and sold under the newly created Dino marque. Even on the cylinder block casting, the name FIAT was visible which was not in line with the newly created DINO make.
The Fiat Dino was introduced as a 2-seater Spider at the Turin Motor Show in October 1966;[5] a 2+2 Coupé version, built on a 270 mm (10.6 in) longer wheelbase, bowed a few months later at the Geneva Motor Show in March 1967.[6] The two bodies showed very different lines, as they had been designed and were manufactured for Fiat by two different coachbuilders: the Spider by Pininfarina, and the Coupé by Bertone—where it had been sketched out by Giorgetto Giugiaro. Curiously the Spider type approval identified it as a 2+1 seater.[2] The Spider had poorer interior trim than the Coupé, below par for its class: the dashboard was covered in vinyl, the metal-spoke steering wheel had a plastic rim, and the interior switchgear was derived from cheaper Fiat models.[4] After a few months this issue was addressed, and Spiders produced after February 1967 had a wood-rimmed steering wheel as well as a wood trim on the dashboard like the sister Coupé car had since the beginning.[4] Option lists for both models were limited to radio, metallic paint, leather upholstery, and for the Spider a vinyl-covered hardtop with roll-bar style stainless steel trim.
The car was offered with an all-aluminium DOHC 2.0 L V6, coupled to a 5-speed manual transmission. The same 2.0-litre engine was used in mid-engined, Ferrari-built Dino 206 GT, which was introduced in pre-production form at the 1967 Turin Motor Show and went on sale in 1968. Fiat quoted 160 PS (118 kW; 158 hp) for the Fiat Dino, while in 1967 Ferrari—presenting the first prototype of the Dino 206 GT—claimed 180 hp (130 kW) despite both engines being made by Fiat workers in Turin on the same production line, without any discrimination as to their destination. Jean-Pierre Gabriel in "Les Ferraris de Turin" notes that, "La declaration de Ferrari ne reposait sur aucun fondament technique"—Ferrari's statement had no technical basis.[7] The real reason for this difference was a mistake in between quotes made in SAE and DIN power output.
In 1969, both Ferrari and Fiat introduced new 2.4-litre Dino models. The Fiat Dino 2400 premiered in October 1969 at the Turin Motor show; besides the larger engine, another notable improvements was independent rear suspension.[8] The V6 now put out 180 PS (132 kW; 178 hp), and used a cast iron instead of the previous light alloy engine block; the same engine was installed on the Dino 246 GT, Ferrari's evolution of the 206. Whereas the original Dino was equipped with a rigid axle suspended by leaf springs and 4 shock absorbers, 2.4-litre cars used a coil-sprung independent rear suspension with 2 shock absorbers derived from the Fiat 130. Rather than engine power and absolute speed, the most important consequence of the larger displacement was a marked increase in torque, available at lower engine speeds; the Dino 2400 had much better pickup, and it was found more usable, even in city traffic.
Source: Wikipedia
